Agilent Technologies B1500A Training Manual

Module 7
Measurement Functions
7-5
VAR1
Primary
VAR2
Secondary
SMU Pulse Mode
Pulse On Primary Source
One SMU can pulse while another follows. Either VAR1 or VAR2 may be pulsed, but not both.
The settings above could be used to pulse a drain while stepping the gate.
