Module 8
Capacitance Measurement
8-6
z You will make the MOS FET Cgs-Vg measurement
z You will learn how to properly define a C-V sweep algorithm
z Use the next several pages as you guide
z Get the CV-1MHz setup
z Follow the instructions on the following pages
To Get Started:
Class Exercise
C-V Sweep Measurement
