Test Setup for Class Exercises
The Demo preset group contains the following test setup. The setup data are only examples
for the class exercises. The following table lists the test setup name in alphabetical order.
Test Setup Name Description
ALWG monitor 511 kohm sampling measurement with SPGU ALWG output
Charge Pumping 4T
0.1
V step
MOSFET I
cp-Vbase measurement
CV-1MHz MOSFET Cgs-Vg measurement
Demo-S-NorFlash
Enduranc
e
MOSFET Endurance test
Fowler-Nordheim Fowler-Nordheim (FN) plot
GMMAX MOSFET sqrt_Id-Vg, PEAK-Vg measurement
GUMMEL Bipolar transistor gummel plot
IDVD MOSFET Id-Vd measurement
IDVD-Pulse MOSFET pulsed Id-Vd measurement
Id-Vd MOSFET Id-Vd measurement, Application Test
IDVG MOSFET Id-Vg measurement
IRVR 511 kohm I-V measurement
IV-res 511 kohm I-V measurement with SMU series resistor
LED LED I-V measurement
Parallel 1 ohm I-V measurement, voltage force and current measurement
PG monitor 511 kohm sampling measurement with SPGU VPULSE output
RC-sampling-log RC sampling measurement, log sampling
REKELV Bipolar transistor Re measurement
R-sampl-neg-hold 511 kohm sampling measurement with negative hold time
Subthreshold MOSFET subthreshold measurement
Trng C-f Direct Control (C-f measurement)
Trng Cgg-Vg Modifying application test definition using vector data
Trng CV MOSFET C-V measurement
Trng Id-Vd MOSFET Id-Vd measurement
