Agilent Technologies E3632A Service Guide

Chapter 6
Replaceable Parts
E3632-60002 Main PC Assembly
106
Reference
Designator
Agilent Part
Number
Qty Part Description Mfr.
Code
Mfr. Part Number
Q7-10 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 03406 MMBT2222A
Q11 1855-0493 1 TRANSISTOR MOSFET P-CHAN E-MODE TO-220 03038 IRF9530N
R1 0699-1380 2 RESISTOR 3.16K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3161
R2-5 0699-1318 15 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R6 0699-1330 5 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R7 0699-1374 1 RESISTOR 1.78K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1781
R8 1699-1425 3 RESISTOR 261 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2610
R9 0699-1391 9 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R10 1699-1415 9 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R11 0811-3839 2 RESISTOR .2 +-1% 5W PWN 01542 0811-3839
R12 0699-2715 1 RESISTOR-FUSE 1 OHM +-5%; 0.5 W @70 01542 0699-1394
R13 0699-1394 6 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1472
R14 0699-1403 3 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3162
R15 0764-0033 1 RESISTOR 33 +-5% 2W MO TC=0+-200 01542 0764-0033
R16 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R17 0811-3839 RESISTOR .2 +-1% 5W PWN 01542 0811-3839
R18 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R19 0699-1405 1 RESISTOR 38.3K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3832
R20 0699-1423 14 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R21 0699-1386 1 RESISTOR 5.62K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5621
R22 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R23 0699-1381 2 RESISTOR 3.48K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3481
R24-26 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R27 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R28 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2610
R29-30 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R31 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R32 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2610
R33 0699-1381 RESISTOR 3.48K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3481
R34 0811-2188 2 RESISTOR 5K +-5% 3W PWI TC=0+-20 01542 0811-2188
R35 0699-1330 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R36 0757-0274 1 RESISTOR 1.21K +-1% .125W TF TC=0+-100 00746 CRB25-FX-1211
R37 0699-1330 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R38 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R39 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R40 0699-3431 2 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-4991
R41 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R42 0699-3431 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-4991
