Chapter 2 Quick Start
To Store and Recall the Instrument State
32
To Store and Recall the Instrument State
You can store up to three different operating states in non-volatile memory.
This also enables you to recall the entire instrument with just a few key presses
from the front panel.
The memory locations are supplied with the reset state from the factory for
front panel operation. Refer to the description of
*RST
command, starting on
page 94 in the User’s Guide for more information.
The following steps show you how to store and recall an operating state.
1
Set up the power supply for the desired operating state.
The storage feature "remembers" the output range selection, the limit value
settings of voltage and current, output on/off state , OVP and OCP on/off state,
and OVP and OCP trip levels.
2
Turn on the storage mode.
Three memory locations (numbered 1, 2, and 3) are available to store the
operating states. The operating states are stored in non-volatile memory and
are remembered when being recalled.
This message appears on the display for approximately 3 seconds.
3
Store the operating state in memory location "3".
Turn the knob to the right to specify the memory location 3.
To cancel the store operation, let the display time-out after about 3 seconds
or press any other function key except the key. The power supply
returns to the normal operating mode and to the function pressed.
Store 1
Store 3
Store
Store
