Chapter 3 Calibration Procedures
Calibration Record for Agilent E3632A
69
3
Calibration Record for Agilent E3632A
Step Calibration Description
Measurement
Mode (DVM)
Supply being
Adjusted
1 Unsecure the power supply (see page 59).
2
Turn on "CAL MODE"(simultaneously press "Calibrate" and "Power" keys)
until it beeps.
3 Move down menu to "CAL SETUP 1" (press "Calibrate" key).
Voltage
Calibration
4
Calibrate DAC and select the low point for voltage calibration; "START
BITCAL" appears for 3 seconds and the display counts down numbers from
30 to 0. Then, " V LO 0.5000 V" appears on the display(press "Calibrate" key
and wait about 30 seconds; then change the display to match the DVM
reading).
V
DAC and low
voltage point
calibration
5
"V MI 15.000 V" appears on the display (press "Calibrate" key; then change
the display to match the DVM reading).
V
Middle voltage
point calibration
6
"V HI 29.500 V" appears on the display (press "Calibrate" key; then change
the display to match the DVM reading).
V
High voltage point
calibration
7 "CAL SETUP 2" now appears on the display (press "Calibrate" key). V OVP calibration
8
"CAL SETUP 3" now appears on the display (press "Calibrate" key; then
connect 0.019resistor across the output terminals).
Current
calibration
9
"I LO 0.200 A" appears on the display (press "Calibrate" key; then change
the display to match the computed current through 0.019resistor).
A
Low current point
calibration
10
"I MI 3.500 A" appears on the display (press "Calibrate" key; then change the
display to match the computed current through 0.019resistor).
A
Middle current
point calibration
11
"I HI 6.9000 A" appears on the display (press "Calibrate" key; then change
the display to match the computed current through 0.019resistor).
A
High current point
calibration
12 "CAL SETUP 4" now appears on the display (press "Calibrate" key). A OCP calibration
13 Press "Calibrate" key, then press "Power" switch. Exit CAL MODE
