E3632-60002 Main PC Assembly
109
6
Reference
Designation
Agilent Part
Number
Qty Part Description Mfr.
Code
Mfr. Part Number
R141-142 0699-1375 2 RESISTOR 1.96K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1961
R143-144 0699-1447 2 RESISTOR 261K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2613
R145 0699-1449 RESISTOR 348K +-0.1% .125W TKF TC=0+-100 00746 MCR18-F-X-3483
RV1-6 0837-0261 6 DIODE-VRTS 03799 V275LA20A
S1 3101-3230 1 SWITCH-PB DPSTALTNG 6A 250V VAC/VDC 04486
NE18-CTII-2A-EE-X
U1 1820-6176 1 IC-INTERFACE XCVR BIPOLAR BUS OCTL 01698 SN75ALS160DW
U2 1820-6175 1 IC-INTERFACE XCVR BIPOLAR BUS OCTL 01698 SN75ALS162DW
U3 1821-1721 1 IC-GPIB CONTROLLER 01698 MP9914FNL
U4
34401-88842
1 IC(34401-88805)8BIT MCU 87C51 01542 34401-88842
U5 1820-6470 1 IC SCHMITT-TRIG CMOS/HCT INV HEX 02037 74HCT14AD
U6-7 1990-1552 2 OPTO-ISOLATOR LED-IC GATE IF=10MA-MAX 01542 HCPL-2211-300
U8 1820-5478 1 IC FF CMOS/HCT D-TYPE POS-EDGE-TRIG 01542 1820-5478
U9 1820-7662 1 IC-INTERFACE DRVR/RCVR BIPOLAR DUAL 01542 1820-5478
U10 1826-0144 1 IC PWR MGT-V-REG-FXD-POS 4.8/5.2V TO-220 01542 1826-0144
U11 1826-3755 1 IC PWR MGT-V-REG-FXD-POS 4.75/5.25V 5 01542 1826-2461
U12 1826-0393 1 IC PWR MGT-V-REG-ADJ-POS 1.2/37V 3 PINS 01542 1826-0393
U13
E3632-60016
1 IC 2M-BIT OTP 150-NS CMOS 01542 1818-5187
U14 1818-4777 1 IC 256K-BIT SRAM 70-NS CMOS 01542 1818-4777
U15 1818-5236 1 IC 4K-BIT EEPROM 500-NS CMOS 01542 1818-5236
U16 1826-0527 1 IC PWR MGT-V-REG-ADJ-NEG 1.2/37V 3 PINS 01542 1826-0527
U17 1821-1479 1 IC 16-BIT MCU I/O TIMER 01542 1821-1479
U18 1820-8907 1 IC-ASIC GT-ARY 600 GATES CMOS SCX6200 01542 1820-8907
U19 1820-5937 1 IC FF CMOS/AC D-TYPE POS-EDGE-TRIG 01542 1820-5937
U20 1990-1659 5 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 1990-1659
U21 1826-2793 1 D/A 16-BIT 16-P-SOIC BICMOS 01542 1826-2793
U22 1820-5790 1 IC SHF-RGTR CMOS/HC SYNCHRO SERIAL-IN 01542 1820-5790
U23-24 1990-1659 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 1990-1659
U25 1821-0434 2 IC ANLG-MUXR/DEMUXR CMOS/HC 8-CHANNEL 01542 1821-0434
U26 1826-1991 1 IC OP AMP HS SINGLE 8 PIN PLSTC-SOIC 01542 1826-1991
U27 1821-0434 IC ANLG-MUXR/DEMUXR CMOS/HC 8-CHANNEL 01542 1821-0434
U28 1990-1659 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 1990-1659
U29 1826-1925 2 IC OP AMP LOW-NOISE SINGLE 8 PIN 01542 1826-1925
U30 1826-1811 1 IC OP AMP LOW-BIAS-H-IMPD DUAL 8 PIN 01542 1826-1811
U31 1826-1622 3 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN 01542 1826-1622
U32 1826-2420 3 IC OP AMP LP DUAL 8 PIN PLATC-SOIC 01542 1826-2420
U33 1820-4346 1 IC MUXR/DATA-SEL CMOS/HC 01542 1820-4346
U34-35 1826-2801 2 IC PWR MGT-OV-V-SEN 8 PINS P-SOIC PKG 01542 1826-2801
U36 1990-1659 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 1990-1659
