Chapter 6 Replaceable Parts
E3632-60004 Front Panel Display PC Assembly
111
6
E3632-60004 Front Panel Display PC Assembly
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
C1-C3 0160-6497 14 CAP-FXD 0.1uF+-10%50V CER COG 01542 0160-6497
C4-C5 0180-3751 2 CAP-FXD 1uF+-20%35V TA 01542 0180-3751
C6 0160-5945 3 CAP-FXD 0.01uF+-10%50V CERX7R 01542 0160-5945
C7-C8 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 01542 0160-6497
C9 0160-5945 CAP-FXD 0.01uF+-10%50V CERX7R 01542 0160-5945
C10-C15 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 01542 0160-6497
C16-C17 0160-5947 2 CAP-FXD 1000pF+-10% 50V CER COG 01542 0160-5947
C18 0160-5945 CAP-FXD 0.01uF+-10%50V CERX7R 01542 0160-5945
C19-C20 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 01542 0160-6497
C25 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 01542 0160-6497
CR1 1906-0291 1 DIODE-DUAL 70V 100mA TO-236 AA 01542 1906-0291
CR2 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236(SOT-23) 01542 BZX84C6V2
Q1-Q2 1854-1053 2 TRANSISTOR NPN SI SOT-23(TO-236AB) 01542 1854-1053
R1-R4 0699-1348 4 RESISTOR 14.7 +-1% .125W TKF TC=0+-100 00746 MCR18FX
R5 0699-1391 8 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R6 0699-1400 2 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R7-R9 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R10 0699-1318 1 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R11 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 00746
R12 0699-1378 1 RESISTOR 2.61K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R13-R15 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R16-R19 0699-1423 4 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18FX
R20-R21 0699-1330 2 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18FX
R22 0699-1400 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 00746 MCR18FX
U1 1820-5330 1 IC-INTERFACE DRVR BIPOLAR DISPLAY 01542 1820-5330
U2 1826-1402 1 IC PWR MGT-V-REG-FXD-POS 4.8/5.2V 8PINS 01542 1826-1402
U3 1826-2264 1 IC PWR MGT-UND-V-SEN 8 PINS P-SOIC PKG 01542 1826-2264
U4 1820-5562 1 IC GATE CMOS/HC NOR QUAD 2-INP 01542 1820-5562
U5 1820-5478 1 IC FF CMOS/HCT D-TYPE POS-EDGE-TRIG 01542 1820-5478
U6 1820-6756 1 IC SHF-RGTR COMS/HC MULTI-MODE 01542 1820-6756
U7
34401-88804
1 IC-8-BIT MCU W/4K EPROM;12MHZ 01542 34401-88804
U8 1826-1528 1 IC COMPARATOR LP QUAD 14PIN PLSTC-SOIC 01542 1826-1528
U9
E3632-60010
1 VFD E3632A 01542 E3632-60010
Y1 0410-4009 1 RESONATOR-CERAMIC 12mhz SATABILITY=.1 01542 0410-4009
J1 1252-7161 1 CONNECTOR-TIN-PLATED 12P(RIGHT-ANGLE) 01542 1252-7161
