E3633/E3634-60002 Main PC Assembly
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C1 0180-4228 1 CAP-FXD 47uF +-20% 10V TA 12340 T491D476M010AS
C2-6 0160-6497 45 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C7 0180-3751 4 CAP-FXD 1uF +-20% 35 V TA 12340 T491B105M035AS
C8-9 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C10 0180-4854 2 CAP-FXD 2200uF +-20% 35 V AL-ELCTLT 06360 KMG1V222H
C11 (3633A)
(3634A)
0180-4235
0180-3595
4
2
CAP-FXD 470uF +-20% 50 V AL-ELCTLT
CAP-FXD 220uF +-20% 100 V AL-ELCTLT
12599
00779
KME50VB471M12X20LL
UPR2A221RH
C12-14 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C15-16 0160-7746 2 CAP-FXD 0.33uF +- 5% 25V CER X7R 02010 12103C334JATMA
C17 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C18-19 0180-4853 2 CAP-FXD 2200uF +-20% 50 V AL-ELCTLT 06360 KMG1H222H
C20 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C21 0180-3643 1 CAP-FXD 470uF +-20% 25 V AL-ELCTLT 06360 SME25VB471M10X16LL
C22 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C23 0180-4854 CAP-FXD 2200uF +-20% 35 V AL-ELCTLT 06360 KMG1V222H
C24-25 0160-6225 2 CAP-FXD 0.33uF +-10% 250 V POLYE-MET 06127 MKS4-.33/250/10
C26-27 0180-4116 3 CAP-FXD 22uF +-20% 20 V TA 12340 T491D226M020AS
C28 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C29 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C30 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C31-32 0160-5947 2 CAP-FXD 1000pF +-10% 50V CER X7R 06352 C2012X7R1H102K
C33 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C34 0160-6940 2 CAP-FXD 0.33uF +-20% 50 V CER Z5U 12340 C1210C334M5UAC
C35 0180-3751 CAP-FXD 1uF +-20% 35 V TA 12340 T491B105M035AS
C36-37 0160-5550 2 CAP-FXD 0.1 uF +-5% 100V POLYC-MET 10200 MC1-9196J
C38 0180-3751 CAP-FXD 1uF +-20% 35 V TA 12340 T491B105M035AS
C39 (3633A)
(3634A)
0180-4568
0180-4855
3
CAP-FXD +-20% 63 V AL-ELCTLT
CAP-FXD +-20% 80 V AL-ELCTLT
00779
00779
LLQ1J123MHSC
LLQ1K103MHSC
C40 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C41 0160-6940 CAP-FXD 0.33uF +-20% 50 V CER Z5U 12340 C1210C334M5UAC
C42-43 0160-6497 2 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C44 0160-6736 4 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C45 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C46 (3633A)
(3634A)
0180-4568
0180-4855
CAP-FXD +-20% 63 V AL-ELCTLT
CAP-FXD +-20% 80 V AL-ELCTLT
00779
LLQ1J123MHSC
LLQ1K103MHSC
C47 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
109
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
To Next Page
