Agilent Technologies E3634A Service Guide

Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C48 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C49 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C50 0160-5954 3 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C473K5RAC
C51 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C52 0160-5954 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C473K5RAC
C53-56 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C57 0180-3744 1 CAP-FXD 4.7uF +- 20% 10V TA 12340 T491B475M010AS
C58-59 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C60-65 0160-5892 7 CAP-FXD 0.22uF +-10% 63V POLYE-MET 11892 MMK5224K63L6
C66-68 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C69,70 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C71 0180-3751 CAP-FXD 1uF +-20% 35 V TA 12340 T491B105M035AS
C72 0160-5944 2 CAP-FXD 0.047uF +-10% 50 V CER X7R 12340 C0805C473K5RAC
C73 0180-4575 2 CAP-FXD 47uF +-10% 20 V TA 12340 T491D476K020AS
C74 (3633A)
(3634A)
0180-4568
0180-4855
CAP-FXD +-20% 63 V AL-ELCTLT
CAP-FXD +-20% 80 V AL-ELCTLT
00779
LLQ1J123MHSC
LLQ1K103MHSC
C75 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C76-80 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C81 (3633A)
(3634A)
0160-7332
0160-6105
2
1
CAP-FXD 6800pF +-10% 50 V CER X7R
CAP-FXD 2700pF +-5% 50 V CER C0G
12340
C1206C682K5RAC
C1206C272J5GAC
C82 0160-6734 1 CAP-FXD 0.047uF +-10% 50V CER X7R 12340 C0805C473K5RAC
C83 0160-7021 1 CAP-FXD 56pF +-5% 50 V CER C0G 12340 C1206C560J5GAC
C84 0160-7332 CAP-FXD 6800pF +-10% 50 V CER X7R 12340 C1206C682K5RAC
C85 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C86 0160-7711 1 CAP-FXD 4700pF +-10% 50 V CER X7R 12340 C0603C472K5RAC
C87 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C88-89
(3633A)
(3634A)
0160-6980
0160-8673
3
2
CAP-FXD 39pF +-1% 50 V CER C0G
CAP-FXD 680pF +-5% 100 V CER C0G
12340
C1206C390J5GAC
C1206C681J1GAC
C90 0160-5944 CAP-FXD 0.047uF +-10% 50 V CER X7R 12340 C0805C473K5RAC
C91-92 0160-6497 CAP-FXD 0.1uF +10% 50 V CER X7R 12340 C1206C104K5RAC
C93 0160-3237 2 CAP-FXD 0.1uF +-20% 50 V CER Z5U 01542 RPE132Z5U104M50
C94 0160-6104 1 CAP-FXD 2200pF +-5% 50 V CER C0G 12340 C1206C222J5GAC
C95 0160-6497 CAP-FXD 0.1uF +10% 50 V CER X7R 12340 C1206C104K5RAC
C96 0160-5954 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C473K5RAC
C97-98 0180-4235 CAP-FXD 470uF +-20% 50 V AL-ELCTLT 06360 KME50VB471M12X20LL
C99 0160-4065 1 CAP-FXD 0.1uF +-20% 250V PPR-MET 11892 PME271M610M
C100 0160-5892 CAP-FXD 0.22uF +-10% 63V POLYE-MET 11892 MMK5224K63L6
C101-102 0180-3469 2 CAP-FXD 100uF +-20% 35 V AL-ELCTLT 06360 KME35VB101M8X11LL
110
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
