Agilent Technologies E3634A - Page 112

Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C103-104 0160-4183 2 CAP-FXD 1000pF +-20% 250V PPR-MET 11892 PME271Y410M
C105
(3633A)
(3634A)
0180-4235
0180-3595
CAP-FXD 470uF +-20% 50 V AL-ELCTLT
CAP 220UF 100V 20% AL
12599
00779
KME50VB471M12X20LL
UPR2A221RH
C106
(3633A)
(3634A)
0160-4535
0160-5755
CAP-FXD 1uF +-10% 50 V CER X7R
CAP 0.1UF 100V CER X7R
00901
C330C105K5R5CA
C192C104K1R5CA
C107 0160-6980 CAP-FXD 39pF +-1% 50 V CER C0G 12340 C1206C390J5GAC
C108-109 0150-0012 2 CAP-FXD 0.01uF +-20% 1 kV CER Z5U 09859 562CAB102AJ103MA22
C110 0160-3237 CAP-FXD 0.1uF +-20% 50 V CER Z5U 01542 RPE132Z5U104M50
C111
(3633A)
(3634A)
0160-5957
0160-6980
1 CAP-FXD 47pF +-5% 50 V CER C0G
CAP 39PF 5% 50V CER COG
12340
C0805C470J5GAC
C1206C390J5GAC
C112 0160-4697 CAP-FXD 0.1uF +10% 50 V CER X7R 12340 C1206C104K5RAC
CR1 1906-0407 3 DIODE-FW BRDG 400V 1A 04504 DF04S
CR2-3 1906-0291 7 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR4 1906-0407 DIODE-FW BRDG 400V 1A 04504 DF04S
CR6 1902-0579 3 DIODE-ZNR 5.1V 5% PD=1W IR=10UA 02037 1N4733ARL
CR7 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236 (SOT-23 06337 BZX84C6V2
CR8 1906-0407 DIODE-FW BRDG 400V 1A 04504 DF04S
CR9-10 1902-1570 2 DIODE-ZNR 2.4V 5% TO-236 (SOT-23) PD=.3W 03334 BZX84-C2V4
CR11-12 1901-1335 2 DIODE-PWR RECT 400V 1A 50NS 02037 MURS140T3
CR13 1901-1227 9 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR14 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR15 1901-1332 1 DIODE-PWR-S 40V 1A 02037 MBRS140T3
CR16 1902-1304 1 DIODE-ZNR 1N965B 15V 5% DO-35 PD=.5W 02037 1N965B
CR17 1884-0332 2 THYRISTOR-SCR 02037 MCR264-00
CR18 1901-1227 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR19 1884-0332 THYRISTOR-SCR 02037 MCR264-00
CR20-23 1901-1227 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR24-25 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR26 1902-0579 DIODE-ZNR 5.1V 5% PD=1W IR=10UA 02037 1N4733ARL
CR27-28 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR29-30 1901-1065 2 DIODE-PWR RECT 1N4936 400V 1A 200NS 22280 1N4936
CR31 1906-0291 5 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR32 1902-0579 DIODE-ZNR 5.1V 5% PD=1W IR=10UA 02037 1N4733ARL
CR33 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR34 1901-1227 DIODE-SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR35-36 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
111
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
