Agilent Technologies E3634A Service Guide

Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
CR37 1901-1227 DIODE-SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR38 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR39 1884-0332 1 THYRISTOR-SCR TO-220AB VRRM=200 02037 MCR264-00
CR40 1901-1227 DIODE-SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR41-42
(3633A)
(3634A)
1901-1542
1906-0261
2
DIODE-ULT-FST-RCRY 400V 30A 60NS
DIODE PWR 150V 16A
02910
02037
RURG3040
MUR1615CT
CR44 1906-0480 1 DIODE-FW BRDG 200V 35A 22280 GBPC3502W
CR45 1902-0052 1 DIODE-ZNR 6.8V 2% 0.4W 01542 1902-0052
E4 9164-0173 1 ALARM-AUDIBLE PIEZO ALARM PIN TYPE; 25V 09939 PKM22EPP-4002 S
E5-10 9170-1431 6 CORE-SHIELDING BEAD 06352 HF50ACB-453215
E11 9170-1506 1 CORE-SHIELDING BEAD 06352 HF50ACB201209
F1-3 0699-2715 3 RESISTOR-FUSE 1 OHM +-5%; 0.5 W @70 01542 FN1/2
JP1-5 1251-4682 5 CONN-POST TYPE .100-PIN-SPCG-MTG-END 03418 22-10-2031
P1 1252-2161 1 CONN-RECT MICRORBN 24-CKT 24-CONT 01542 554923-2
P2 1252-2266 1 ONN-RECT D-SUBMIN 9-CKT 9-CONT 01542 748959-1
P3 1251-5066 2 CONN-POST TYPE 2.5-PIN-SPCG-MTG-END 01542 22-04-1021
P4 1252-8092 1 CONN-POST TYPE 3.96-PIN-SPCG-MTG-END 01542 09-65-2088
P5 1251-8363 1 CONN-POST TYPE .156-PIN-SPCG-MTG-END 01542 09-65-2038
P6 1252-7162 1 CONN-POST TYPE 2.0-PIN-SPCG-MTG-END 01542 00-8283-12-12-00-000
P7-9 1252-2771 3 CONNECTOR-SGL QDISC-M .25-IN-BSC-SZ 01542 63067-1
P10 1252-8093 1 CONN-POST TYPE 3.96-PIN-SPCG-MTG-END 01542 09-65-2068
P11 1251-5066 CONN-POST TYPE 2.5-PIN-SPCG-MTG-END 03418 22-04-1021
Q2-3 1854-1053 2 TRANSISTOR NPN SI SOT-23 (TO-236AB) 03406 MMBT2222ALT1
Q4 1853-0281 1 TRANSISTOR PNP 2N2907A SI TO-18 PD=400MW 02037 2N2907A
Q5-6
(3633A)
(3634A)
1855-1122
2
TRANSISTOR MOSFET N-CHAN TO-247AC
03038
IRFP064
Q7 1855-0493 1 TRANSISTOR MOSFET P-CHAN E-MODE TO-220 03038 IRF9530N
R1 0699-1318 16 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R2 0699-1380 2 RESISTOR 3.16K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3161
R3-R4 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R5 0699-1330 4 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R6 0699-1374 1 RESISTOR 1.78K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1781
R7 0699-1391 8 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R8 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R9 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R10 0699-1405 1 RESISTOR 38.3K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3832
R11-12 0699-1423 15 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
112
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
1855-1651 IRFP260NTRANSISTOR MOSFET N-CHAN E-MODE TO-247
