Agilent Technologies E3634A Service Guide

Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
R13 0699-1386 2 RESISTOR 5.62K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5621
R14 0699-1381 2 RESISTOR 3.48K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3481
R17-18 0699-1415 7 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R19 0699-1425 3 RESISTOR 261 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2610
R20 0764-0033 1 RESISTOR 33 +-5% 2W MO TC=0+-200 01542 FP69 33R0 5%
R21-23 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R24 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R25 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2610
R26 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R27-28 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R29-30 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R31 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R32 0699-1381 RESISTOR 3.48K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3481
R33 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2610
R34 0699-1330 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R35 0757-0274 1 RESISTOR 1.21K +-1% .125W TF TC=0+-100 00746 5053HD1K210F
R36 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R37 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R38 0699-3431 1 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-4991
R39 0811-2188 1 RESISTOR 5K +-5% 3W PWI TC=0+-20 02499 RS-25K05%
R40 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R41 0699-1386 RESISTOR 5.62K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5621
R42 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R43 0699-1348 1 RESISTOR 14.7 +-1% .125W TKF TC=0+-100 00746 MCR18-F-14R7
R44 0699-1344 1 RESISTOR 10 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-10R0
R45 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R46 0699-1382 1 RESISTOR 3.83K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3831
R47 0699-1380 RESISTOR 3.16K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3161
R48-53 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R54 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R55-56 0699-1428 2 RESISTOR 348 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3480
R57 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R58 0699-3211 1 RESISTOR 39.2K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3922
R59 0699-1904 2 RESISTOR 1.62K +-0.1% .25W TF TC=0+-100 00746 MCR18-F-1621
R60 0699-1389 3 RESISTOR 8.25K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-8251
R61 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R62-64 0699-2489 17 RESISTOR 10K +-0.1% .125W TF TC=0+-25 06337 W1206R031002BT
R65 0699-1385 2 RESISTOR 5.11K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5111
113
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
