Agilent Technologies E3634A Service Guide

Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
R66 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R67 0699-1383 1 RESISTOR 4.22K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-4221
R68 0699-1379 1 RESISTOR 2.87K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2871
R69 (3633A)
(3634A)
0699-1404
0699-1406
1
2
RESISTOR 34.8K +-1% .125W TKF TC=0+-100
RESISTOR 42.2K +-1% .125W TKF TC=0+-100
00746
MCR18-F-X-3482
MCR18-F-4222
R70 0699-1400 1 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2612
R71 0699-2491 3 RESISTOR 20K +-0.1% .125W TF TC=0+-25 02499 W1206R032002BT
R72 0699-2837 5 RESISTOR 30K +-0.1% .125W TF TC=0+-25 02499 W1206R033002BT
R73 0699-2843 1 RESISTOR 100K +-0.5% .125W TF TC=0+-25 02499 W1206R031003BT
R74 0699-1406 RESISTOR 42.2K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-4222
R75-82 0699-2489 RESISTOR 10K +-0.1% .125W TF TC=0+-25 06337 W1206R031002BT
R83 0699-1396 1 RESISTOR 17.8K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1782
R84 0699-1415 RESISTOR 100 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1000
R85 0699-1403 3 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3162
R86 0699-1384 2 RESISTOR 4.64K +-1% .125W TKF TC=0+-100 00746 MCR18-F-4641
R87 (3633A) 0699-1394 4
RESISTOR 14.7K +-1% .125W TKF TC=0+-100 00746 MCR18-F-1472
(3634A) 0699-1394 3
R88 0699-1398 1 RESISTOR 21.5K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2152
R89 0699-3602 1 RESISTOR 12.4K +-0.1% .125W TF TC=0+-25 00746 MCR18-F-1472
R90 0699-1389 RESISTOR 8.25K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-8251
R91 (3633A)
(3634A)
0699-3223
0699-5409
2
2
RESISTOR 45.3K +-0.1% .125W TF TC=0+-25
R-C 17.4K 0.1% 1/8W
02499
09891
W1206-R-03-45R3KB
RN73E2B1742B
R92 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R93 0699-1413 1 RESISTOR 82.5K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-8252
R95-97 0699-2489 RESISTOR 10K +-0.1% .125W TF TC=0+-25 02499 W1206R031002BT
R98 0699-2837 RESISTOR 30K +-0.1% .125W TF TC=0+-25 02499 W1206R033002BT
R99 0699-1330 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R100 0699-2506 1 RESISTOR 7.15K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-7151
R101 0699-2489 RESISTOR 10K +-0.1% .125W TF TC=0+-25 06337 W1206R031002BT
R102 0699-2837 RESISTOR 30K +-0.1% .125W TF TC=0+-25 02499 W1206R033002BT
R103 0699-1449 1 RESISTOR 348K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3483
R104 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R105 0699-4527 3 RESISTOR 16.9K +-0.1% .125W TF TC=0+-25 02499 W1206-R-03-1692-B
R106 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R107-108 0699-2837 RESISTOR 30K +-0.1% .125W TF TC=0+-25 02499 W1206R033002BT
R109
(3633A)
(3634A)
0699-1410
0699-2145
1
2
RESISTOR 61.9K +-1% .125W TKF TC=0+-100
RESISTOR 33K +-1% .125W TKF TC=0+-100
00746
MCR18-F-X-6192
MCR18-J-333
114
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
