Agilent Technologies E3634A Service Guide

Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
R110
(3633A)
(3634A)
0699-3223
0699-5409
RESISTOR 45.3K +-0.1% .125W TF TC=0+-25
R-C 17.4K 0.1% 1/8W
02499
09891
W1206-R-03-45R3KB
RN73E2B1742B
R111-112 0699-3577 2 RESISTOR 140K +-0.1% .125W TF TC=0+-25 02499 W1206-R-03-1403B
R113 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R114 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R115 0699-2484 1 RESISTOR 50K +-1% .125W TKF TC=0+-25 09891 W1206R035002BT
R116 0699-3590 3 RESISTOR 22.1K +-0.1% .125W TF TC=0+-25 09891 9C12063A2212BE
R117 0699-1389 RESISTOR 8.25K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-8251
R118 0699-1408 2 RESISTOR 51.1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5112
R119 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 00746 MCR18-F-1472
R120
(3633A)
(3634A)
0699-1394
0699-2489
RESISTOR 14.7K +-1% .125W TKF TC=0+-100
R-C 10K 0.1% 1/8W
00746
02499
MCR18-F-1472
W1206R031002BT
R121
(3633A)
(3634A)
0699-4527
0699-1400 1
RESISTOR 16.9K +-0.1% .125W TF TC=0+-25
R-C 26.1K 1% 1/8W
02499
00746
W1206-R-03-1692-B
MCR18-F-2612
R122 0699-3590 RESISTOR 22.1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2212
R123
(3633A)
(3634A)
0699-1394
0699-2489
RESISTOR 14.7K +-1% .125W TKF TC=0+-100
R-C 10K 0.1% 1/8W
00746
02499
MCR18-F-1472
W1206R031002BT
R124 0699-4527 RESISTOR 16.9K +-0.1% .125W TF TC=0+-25 02499 W1206-R-03-1692-B
R125 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R126 0699-2491 RESISTOR 20K +-0.1% .125W TF TC=0+-25 02499 W1206R032002BT
R127 0699-1408 RESISTOR 51.1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5112
R128 0699-2491 RESISTOR 20K +-0.1% .125W TF TC=0+-25 02499 W1206R032002BT
R129
(3633A)
(3634A)
0699-1330
0699-2837
RESISTOR 100K +-1% .125W TKF TC=0+-100
R-C 30K 0.1% 1/8W
00746
02499
MCR18-F-X-1003
W1206R033002BT
R130
(3633A)
(3634A)
0699-3662
0699-2721
1
RESISTOR 5.36K +-1% .125W TKF TC=0+-100
R-C 3.16K 0.1% 1/8W
00746
02499
MCR18-F-X-5361
W1206R033161BT
R131 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R132 0699-1403 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3162
R133 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R134 0699-2145 1 RESISTOR 33K +-5% .125W TKF TC=0+-200 00746 MCR18-J-W-333
R135
(3633A)
(3634A)
0699-3590
0699-2489
RESISTOR 22.1K +-1% .125W TKF TC=0+-100
R-C 10K 0.1% 1/8W
00746
02499
MCR18-F-X-2212
W1206R031002BT
R136 0699-2127 1 RESISTOR 36.5K +-5% .125W TKF TC=0+-100 00746 MCR18-F-X-3652
R137 0699-2843 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
115
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
