Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
R138 0699-1385 RESISTOR 5.11K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-5111
R139 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 00746 MCR18-F-1472
R140
(3633A)
(3634A)
0699-1904
0699-2489
1 RESISTOR 1.62K +-0.1% .125W TF TC=0+-25
R-C 10K 0.1% 1/8W
01542
02499
0699-3270
W1206R031002BT
R141 0699-1403 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-3162
R142
(3633A)
(3634A)
0683-3025
0761-0068
1
RESISTOR 3K +-5% .25W CF TC=0-400
RES 4.7K 1W 5% MO
06337
02499
5043CX3K000J
RG324K7-%
R143 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R144
(3633A)
(3634A)
0699-5488
0699-5701
1
1
SHUNT SENSE RESISTOR 10MOHM 10W
RES 0.05 0.5% 3W
01542
PBV-R010-F1-1.0
PBV-R050-0.5
R145 0699-1384 RESISTOR 4.64K +-1% .125W TKF TC=0+-100 00746 MCR18-F-4641
R146 0699-1377 1 RESISTOR 2.37K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2371
R147 0698-3627 1 RESISTOR 200 +-5% 2W MO TC=0+-200 02499 FP69 200R 5%
R148 0683-3305 1 RESISTOR 33 +-5% .25W CF TC=0-400 06337 5043CX33R00J
R149 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R150-151 0699-1375 2 RESISTOR 1.96K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1961
RV1-6 0837-0261 6 DIODE-VRTS 03799 V275LA20A
S1 3101-2976 1 SW-PB DPST 6A 250V 04486 NE18-2A-EE-SP
U1 34401-88842 1 IC(34401-88805)8BIT MCU 87C51 01542 N83C51FA(R8922)
U2 1990-1552 2 OPTO-ISOLATOR LED-IC GATE IF=10MA-MAX 01542 HCPL-2211-300
U3 1820-6176 1 IC-INTERFACE XCVR BIPOLAR BUS OCTL 01698 SN75ALS160DW
U4 1820-7662 1 IC-INTERFACE DRVR/RCVR BIPOLAR DUAL 01542 LT1180CS
U5 1990-1552 OPTO-ISOLATOR LED-IC GATE IF=10MA-MAX 01542 HCPL-2211-300
U6 1821-1721 1 IC-GPIB CONTROLLER 01698 MP9914FNL
U7 1820-5478 1 IC FF CMOS/HCT D-TYPE POS-EDGE-TRIG 01542 74HCT74D
U8 1820-6470 1 IC SCHMITT-TRIG CMOS/HCT INV HEX 02037 74HCT14AD
U9 1826-0144 1 IC PWR MGT-V-REG-FXD-POS 4.8/5.2V TO-220 01542 MC7805CT
U10 1826-3755 1 IC PWR MGT-V-REG-FXD-POS 4.75/5.25V 5 03406 LM2925T
U11 1820-6175 1 IC-INTERFACE XCVR BIPOLAR BUS OCTL 01698 SN75ALS162DW
U12 1826-0393 1 LM 317 01542 LM317T
U13 (3633A)
(3634A)
E3633-60035
E3634-60035
1
1
IC 2M-BIT OTP 150NS CMOS 01542 AM27C020-150JC
U14 1818-4777 1 IC 256K-BIT SRAM 70-NS CMOS 01542 CXK58257AM-70L
U15 1818-5236 1 IC 4K-BIT EEPROM 500-NS CMOS 01542 ST93C66CM1
U16 1826-0527 1 LM 337 01542 LM337T
U17 1990-1659 3 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 MCP3020Z
116
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
