Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
U18 1990-1659 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 MCP3020Z
U19 1821-1479 1 IC 16-BIT MCU I/O TIMER 01542 N80C196KB
U20 1820-8907 1 IC-ASIC GT-ARY 600 GATES CMOS SCX6200 01542 SCX6206AK0
U21 1820-5937 1 IC FF CMOS/AC D-TYPE POS-EDGE-TRIG 01542 74AC74SC
U22 1826-2793 1 D/A 16-BIT 16-P-SOIC BICMOS 01542 AD1851R
U23 1820-5790 1 IC SHF-RGTR CMOS/HC SYNCHRO SERIAL-IN 01542 74HC4094D
U24 1821-0434 2 IC ANLG-MUXR/DEMUXR CMOS/HC 8-CHANNEL 01542 74HC4051D
U25 1826-1991 1 IC OP AMP HS SINGLE 8 PIN PLSTC-SOIC 01542 AD711JR
U26 1821-0434 IC ANLG-MUXR/DEMUXR CMOS/HC 8-CHANNEL 01542 74HC4051D
U27 1826-4018 1 PHASE CONTROL IC SINGLE 16 PIN DIP-P 06121 TCA785
U28 1826-1925 2 IC OP AMP LOW-NOISE SINGLE 8 PIN 01542 OP-27GS
U29 1826-1811 3 IC OP AMP LOW-BIAS-H-IMPD DUAL 8 PIN 01542 TL072ACD
U30 1826-1622 3 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN 01542 TL074CD
U31 1826-2420 3 IC OP AMP LP DUAL 8 PIN PLATC-SOIC 01542 AD706002JR
U32 1820-4346 1 IC MUXR/DATA-SEL CMOS/HC 01542 74HC4053D
U33 1826-2801 2 IC PWR MGT-OV-V-SEN 8 PINS P-SOIC PKG 01542 MC3423D
U34 1826-1811 IC OP AMP LOW-BIAS-H-IMPD DUAL 8 PIN 01542 TL072ACD
U35 1826-1925 IC OP AMP LOW-NOISE SINGLE 8 PIN 01542 OP-27GS
U36 1826-1622 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN 01542 TL074CD
U37 1826-2801 IC PWR MGT-OV-V-SEN 8 PINS P-SOIC PKG 01542 MC3423D
U38 1826-0147 1 IC PWR MGT-V-REG-FXD-POS 11.5/12.5V 02037 MC7812CT
U39 1826-0221 1 IC PWR MGT-V-REG-FXD-NEG -11.5/-12.5V 02037 MC7912CT
U40 1826-1838 1 IC PWR MGT-V-REF-FXD 4.95/5.05V 8 PINS 01542 LT1021DCS8-5
U41 1826-2420 IC OP AMP LP DUAL 8 PIN PLATC-SOIC 01542 AD706002JR
U42 1826-1622 IC OP AMP LOW-BIAS-H-IMPD QUAD 14 PIN 01542 TL074CD
U43 1826-2420 IC OP AMP LP DUAL 8 PIN PLATC-SOIC 01542 AD706002JR
U44 1826-1635 1 IC OP AMP LOW-OFS SINGLE 8 PIN 10858 OP-07CS8
U45 1826-1811 IC OP AMP LOW-BIAS-H-IMPD DUAL 8 PIN 01542 TL072ACD
U46 1990-1659 OPTO-ISOLATOR LED-PTRIAC IF=50MA-MAX 01542 MCP3030Z
VR1 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236 (SOT-23) 01542 BZX84C6V2
Y1 0410-4009 1 RESONATOR-CERAMIC 12.0MHZ; STABILITY=.1 01542 PBRC-12.0BR
Y2 1813-0827 1 CLK-OSC-XTAL STD 12.000-MHZ 0.01% 01542 SG-615P-12.000MC
E3633-60016 1 TERMINAL BLOCK ASSY 01542 E3633-60016
2110-1030 1
FUSE 6.3A 250V TD FE UL-REC IEC
(for option STD, 0E9)
02805 S506-6.3A
2110-1031 1
FUSE (METRIC) 3.15A 250V TD FE UL-REC
(for option 0E3)
02805 S506-3.15A
117
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
