Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C301-302* 0160-5959 2 CAP-FXD 33PF 5% 50V CER 12340 C0805C330J5GAC
C303* 0160-5967 1 CAP-FXD 100PF 5% 50V CER 12340 C0805C101J5GAC
C304* 0160-4535 1 CAP 1UF 50VDC CER 10% 12340 C330C105K5R5CA
C305 0180-4575 1 CAP-FXD 47uF +-10% 20V TA 12340 T491D476K020AS
CR301-302*
CR303
1901-1227
1901-1227
2
1
DIODE SWITCHING 75V 200MA 6NS TO-230
DIODE SWITCHING 75V 200MA 6NS TO-230
02910
02910
BAS16
BAS16
R301* 0699-2145 1 R-C 33K 1% 1/8W 00746 MCR18-J-333
R302* 0699-1408 1 R-C 51.1K 1% 1/8W 00746 MCR18-F-5112
R303* 0699-5553 1 R-C 14.3K 1% 1/8W TF 00746 MCR18-F-X-1432
R304-305* 0699-1369 2 R-C 1.1K 1% 1/8W 00746 MCR18-F-1101
R306* 0699-1430 1 R-C 422 1% 1/8W TKF 00746 MCR18-F-4220
R307 0699-1398 1 R-C 21.5K 1% 1/8W 00746 MCR18-F-2152
R308 0699-1385 1 R-C 5.11K 1% 1/8W 00746 MCR18-F-5111
R309 0699-1381 1 R-C 3.48K 1% 1/8W 00746 MCR18-F-3481
Q301 1854-1053 1 TRANSISTOR NPNN SI SOT-23(TO-236AB) 03406 MMBT2222ALT1
U301* 1826-1811 1 IC OP AMP LOW-BIAS-H-IMPD DUAL 8 PIN 01542 TO072ACD
U302* 1990-1276 1 IC OPTO-ISLTR CNY17GF-1Z 06121 CNY17F-1
* For use with E3634A model only
118
Chapter 6 Replaceable Parts
E3633/E3634-60002 Main PC Assembly
CR46*
1
UF4004
71744DIODE-PWR RECT 400V 1A 50NS DO-41
1901-1149
To Next Page
