E3633-60003 Front-Panel Display PC Assembly
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C1-3 0160-6497 14 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C4-5 0180-3751 2 CAP-FXD 1uF +-20% 35 V TA 12340 T491B105M035AS
C6 0160-5945 3 CAP-FXD 0.01uF +-10% 50 V CER X7R 12340 C0805C103K5RAC
C7-8 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C9 0160-5945 CAP-FXD 0.01uF +-10% 50 V CER X7R 12340 C0805C103K5RAC
C10-15 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C16-17 0160-5947 2 CAP-FXD 1000pF +-10% 50 V CER X7R 12340 C0805C102K5RAC
C18 0160-5945 CAP-FXD 0.01uF +-10% 50 V CER X7R 12340 C0805C103K5RAC
C19-20 0160-6497 1 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
C25 0160-6497 CAP-FXD 0.1uF +-10% 50 V CER X7R 12340 C1206C104K5RAC
CR1 1906-0291 1 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR2 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236 (SOT-23) 02910 BZX84C6V2
Q1-2 1854-1053 2 TRANSISTOR NPN SI SOT-23 (TO-236AB) 03406 MMBT2222ALT1
R1-4 0699-1348 4 RESISTOR 14.7 +-1% .125W TKF TC=0+-100 00746 MCR18-F-14R7
R5 0699-1391 8 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R6 0699-1400 2 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2612
R7-9 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R10 0699-1318 1 RESISTOR 1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1001
R11 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R12 0699-1378 1 RESISTOR 2.61K +-1% .125W TKF TC=0+-100 00746 MCR18-F-2611
R13-15 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1002
R16-19 0699-1423 4 RESISTOR 215 +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2150
R20-21 0699-1330 2 RESISTOR 100K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-1003
R22 0699-1400 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 00746 MCR18-F-X-2612
U1 1820-5330 1 IC-INTERFACE DRVR BIPOLAR DISPLAY 07221 HV518PJ
U2 1826-1402 1 IC PWR MGT-V-REG-FXD-POS 4.8/5.2V 8 PINS 03406 LM78L05ACM
U3 1826-2264 1 IC PWR MGT-UND-V-SEN 8 PINS P-SOIC PKG 02037 MC34064D-5
U4 1820-5562 1 IC GATE CMOS/HC NOR QUAD 2-INP 02037 MC74HC02AD
U5 1820-5478 1 IC FF CMOS/HCT D-TYPE POS-EDGE-TRIG 02910 74HCT74D
U6 1820-6756 1 IC SHF-RGTR CMOS/HC MULTI-MODE 02037 MC74HC299D
U7 34401-88804 1 IC-8-BIT MCU W/4K EPROM;12MHz 01542 34401-88804
U8 1826-1528 1 IC COMPARATOR LP QUAD 14 PIN PLSTC-SOIC 03406 LM339M
U9 E3633-60012 1 VFD, E3633A 01542 E3633-60012
Y1
J1
0410-4009
1252-7161
1
1
RESONATOR-CERAMIC 12.0MHZ; STABILITY=.1
CONN-POST TYPE 2.0-PIN-SPCG-MTG-END
00830
01542
PBRC-12.00BR07
1252-7161
119
Chapter 6 Replaceable Parts
E3633-60003 Front-Panel Display PC Assembly
