20 Chapter 1
Installation and Setup
Printer Setup and Operation
Unsupported printer, Printer Type set to None
This indicates that the analyzer has successfully identified the connected printer, but the printer
is not supported by the analyzer. As long as
None is selected in the Printer Type menu, the
analyzer will respond to any print command by displaying the message Printer Type is
None in the display status line.
7. Select the desired paper size by pressing
Print Setup, More, Page Size, then choose the
appropriate page size for which your printer is configured. This setting will remain unchanged with
Preset or Power Cycle.
The factory default page size is
Letter. The page size will be reset to Letter if System, More,
Restore Sys Defaults is executed.
Testing Printer Operation
When you have completed the analyzer’s printer setup, press
Print Setup, then press Print on the
front panel. If the printer is ready and the printer setup was successful, a printout of the analyzer
display will be printed. If the printer is not ready, the message Printer Timeout will appear on the
analyzer display. Printer Timeout will remain on the display until the printer is ready or until you
press
ESC to cancel the printout request.
NOTE There may be some small discrepancies in the color mapping of the analyzer
display to your color printer. Due to differences in display and printer
technologies, the default display colors do not map exactly to the printer colors.
For example trace 1 is yellow on your analyzer display while it maps to green on
your printer.
