84 Chapter 5
Options and Accessories
Accessories
Carrying Strap (Part Number E4401-60028)
This carrying strap comes with Options AYT and AYU. It can also be ordered separately and used with
Agilent ESA analyzers.
External Keyboard
You may use any IBM AT compatible keyboard with a mini DIN connector. Screen titles and filenames
can be entered with the external keyboard.
GPIB Cable
For use with Option A4H. The Agilent 10833 Series GPIB cables interconnect GPIB devices and are
available in four different lengths (0.5 to 4 meters). GPIB cables are used to connect controllers to a
spectrum analyzer.
USB/GPIB Cable
For use with Option A4H. The Agilent 82357A USB/GPIB interface provides a direct connection from
the USB port on your laptop or desktop PC to GPIB instruments. It comes with the SICL and VISA
software for Windows® 98 (SE)/Me/2000/XP. Using VISA software, your existing GPIB programs
work immediately, without modification. The 82357A is a standard Plug and Play device and you can
interface with up to 14 GPIB instruments.
HP/Agilent 11970 Series Harmonic Mixers
The 11970 Series harmonic mixers are available to extend the frequency range of analyzers with Option
AYZ (external mixing) up to 110 GHz. The following six models are available:
Table 5-1.
HP/Agilent Model
Number
Frequency Range
11970K 18.0 to 26.5 GHz
11970A 26.5 to 40.0 GHz
11970Q 33.0 to 50.0 GHz
11970U 40.0 to 60.0 GHz
11970V 50.0 to 75.0 GHz
11970W 75.0 to 110 GHz
