Chapter 1 7
Installation and Setup
Initial Inspection
Initial Inspection
Inspect the shipping container and the cushioning material for signs of stress. Retain the shipping
materials for future use, as you may wish to ship the analyzer to another location or to Agilent
Technologies for service. Verify that the contents of the shipping container are complete. The
following table lists the items shipped with the analyzer.
Item Description
Accessories
Adapter, Type-N (m) to BNC (f) Not shipped with Option 1DP. Two adapters are shipped with Option
1DN.
Adapter, BNC (m) to F (f), 75 Shipped only with Option 1DP. Two adapters shipped with Option
1DQ.
Adapter, Type-N (m) to SMA (f) Shipped only with Option 1DN for Agilent E4402B, E4403B,
E4404B, E4405B, E4407B, and E4408B. Not shipped with
Option BAB.
Adapter, APC 3.5 (f) to APC 3.5 (f) Shipped only with Option BAB.
Adapter, BNC (f) to SMA (m) Shipped only with Option BAB.
Cable, BNC (m) to BNC (m), 203 mm Shipped only with Agilent E4402B, E4403B, E4404B, E4405B,
E4407B, and E4408B.
Cable, SMA (m) to Type-N (m), 220 mm Shipped only with Option 1DN for Agilent E4402B, E4403B,
E4404B, E4405B, E4407B, and E4408B.
IntuiLink Toolbar software, CD-ROM Provides a set of connectivity tools that enable you to easily move data
from your analyzer to your PC.
Power Cable (See Table 1-3 on page 12) Connection for power source.
Standard Documentation Set
Getting Started Guide Covers unpacking and setting up the analyzer, analyzer features, and
how to make a basic measurement. Includes information on options
and accessories, and what to do if you have a problem.
User’s/Programmer’s Guide Describes analyzer features in detail, including front-panel key
descriptions, basic spectrum analyzer programming information, and
SCPI command descriptions.
Measurement Guide Provides details on how to measure various signals, and how to use
catalogs and files.
Specifications Guide Documents specifications, safety, and regulatory information.
Instrument Messages and Functional Tests Includes instrument messages (and suggestions for troubleshooting
them), and manual functional tests.
Programming Conversion Guide Describes SCPI programming command compatibility for 8590, ESA
series analyzers.
