30 Chapter 2
Front and Rear Panel Features
Front Panel Overview
26 Trace mode
W - clear write
M - maximum hold
m - minimum hold
V - view
S - store blank
1 - trace 1
2 - trace 2
3 - trace 3
Trace
27 Average Average On Off
VAvg indicates video average on. PAvg indicates
power average on.
28 Display line
Display Line On Off
29 Amplitude offset Ref Lvl Offst
30 Amplitude scale Scale Type Log Lin
a. A # in front of any display annotation indicates that the function is uncoupled. (Refer to your User’s guide)
b. When the analyzer is set to the external mixer state (Option AYZ), item 6 changes to display Ext Mix in
place of Atten XdB. In addition, if Mixer Bias is on, a +I or I is appended to Ext Mix.
c. When the (*) is displayed, it means that some or all trace data may not match the annotation due to possible
changes in analyzer settings.
d. AA indicates that auto alignment of all analyzer parameters, except the tracking generator and FM
demodulation options, will occur. AB indicates that auto alignment of all analyzer functions except the RF
section (and tracking generator and FM demodulation options) will occur. No indicator will appear if auto
alignment is off.
Table 2-1 Screen Annotation (Continued)
Item Description Associated Function Key
To Next Page
