12 Chapter 1
Installation and Setup
Power Requirements
AC Power Cord
The analyzer is equipped with a three-wire power cord, in accordance with
international safety standards. This cable grounds the analyzer cabinet when
connected to an appropriate power line outlet. The cable appropriate to the original
shipping location is included with the analyzer.
NOTE The front panel switch is a standby switch only; it is not a LINE switch (power
disconnecting device).
WARNING Install the product so that the detachable power cord is readily identifiable
and easily reached by the operator. The detachable power cord is the product
disconnecting device. It disconnects the mains circuits from the mains supply
before other parts of the product. The front panel switch is only a standby
switch and is not a LINE switch. Alternatively, an externally installed switch
or circuit breaker (which is readily identifiable and is easily reached by the
operator) may be used as a disconnecting device.
CAUTION Always use the three-prong AC power cord supplied with this product. Failure to
ensure adequate earth grounding by not using this cord can cause product damage.
Table 1-1. Power Requirements
Description
Specification
a
Voltage, Frequency 100 to 120 Vrms, 50/60/400 Hz
220 to 240 Vrms, 50/60 Hz
Power Consumption, On Base Fully Loaded
< 260 W < 450 W
Power Consumption, Standby < 20 W
a. For greater detail, refer to the Specifications Guide.
