Making a Basic Measurement
Using the Front Panel
Using the Front Panel
Entering Data
When setting measurement parameters, there are several ways to enter or modify
the value of the active function:
Using Menu Keys
Menu Keys (which appear along the right side of the display) provide access to
many analyzer functions. Here are examples of menu key types:
Knob
Increments or decrements the current value.
Arrow Keys
Increments or decrements the current value.
Numeric Keypad
Enters a specific value. Then press the desired terminator (either a unit
softkey, or the
Enter key).
Unit Softkeys
Terminate a value that requires a unit-of-measurement.
Enter Key
Terminates an entry when either no unit of measure is needed, or you want to
use the default unit.
Toggle Allows you to activate or deactivate states.
Example: Toggles the selection (underlined choice) each
time you press the key.
Submenu Displays a new menu of softkeys.
Example: A submenu key allows you to view a new menu of
softkeys related to the submenu key category.
Choice Allows you to make a selection from a list of values.
Example: A choice key displays the currently selected
submenu choice, in this example, dBm. When the
choice is made, the submenu automatically
returns.
Adjust Highlights the softkey and sets the active function.
Examples: Press this type of key and enter a value.
The default for softkeys with an automatic (
Auto)
or manual (
Man) choice is automatic. After you
enter a value, the selection changes to manual.
You can also press the softkey twice to change to
manual.
10.00 dB
Auto Man
Attenuation
To Next Page
