Chapter 5 65
Options and Accessories
Options
204 1xEV-DO Measurement
Personality
Provides 1xEV transmitter measurements:
channel power
ACPR
intermodulation
spectrum emission mask
occupied BW
code domain power (pilot)
EVM (pilot)
QPSK EVM
power statistics CCDF
Requires Option B7J hardware.
210 HSDPA/HSUPA Measurement
Personality
Provides High-Speed Downlink/Uplink Packet Access to support 16QAM
and modulation accuracy. Requires Option BAF.
Requires Option B7J hardware.
211 TD-SCDMA Power
Measurement Personality
Measures the power profile of TD-SCDMA BTS and MS.
212 TD-SCDMA Modulation
Analysis Measurement
Personality
Provides modulation analysis for TD-SCDMA BTS and MS, such as
EVM, code domain analysis, and time domain or frequency domain
analysis. Requires Option B7J.
213 HSDPA/8PSK for TD-SCDMA
Modulation Analysis
Measurement Personality
Provides measurements for high-speed downlink packet access over
TD-SCDMA to support HSDPA/8PSK. Requires Option 212.
214 1xEV-DV Supports 8PSK and 16QAM modulation analysis. Requires Option B78
and B7J. Option 1DS is recommended. Includes measurements:
Composite Rho
Code Domain tests
215 External Source Control
Measurement Personality
Adds external source control to the PSA analyzer for stimulus-response
measurements.
217
Not available
for E4447A
WLAN Measurement
Personality
Provides WLAN transmitter measurements for 802.11 a/b/g.
Requires Option 122 or 140. Also requires Option 123 for center
frequencies above 3 GHz.
219 Noise Figure Measurement
Personality
Provides noise figure measurements:
Limit lines
Loss compensation
Extended frequency (measures up/down converters)
You need the preamp option: Option 1DS to have specified performance
below 3 GHz, or Option 110 to have nominal performance over the entire
frequency range.
226 Phase Noise Measurement
Personality
Provides phase noise measurements:
Monitor spectrum
Spot frequency
Log plot
Option
Number
Name Description
