48 Chapter 2
Installation and Setup
Setting up the System
11. Press Power Meter Config, More, Resolution to select the resolution as
0.001dB or 0.01 dB.
Step 4. Perform system configurations for Sensor Module.
1. Load the Sensor Module Cal Factors. See “Load Cal Factors” on page 52 to
load the file CFDATA.XML to the PSA.
NOTE If you are using a power sensor that does not have a file or data disk containing
calibration factors, you may need to input the calibration factors by hand. See
“Edit Cal Factors” on page 53.
2. Press the
System, More, More, Power Sensor Config keys to enter the menu of
PS Config.
3. Once you have loaded the Cal Factors file, verify the Sensor Module
information, like Model No., Options, Serial No., Cal Date.
4. Press any key in this page to edit and change the parameter if necessary. Your
edits will be lost when the PSA power is shut down unless you press
Update
Power-On Default
to save. Once saved, the current file with your edits will be
loaded by default next time the PSA is powered on.
5. You can press
More, Clear Power Sensor to clear the Power Sensor information
displayed; or press
Recall Power-On Default to load the default file you saved in
memory.
