Agilent Technologies E444xAU Option H37 Service Guide

Chapter 10 265
Replaceable Parts Lists and Locations
Hardware
Reference
Designator
Description Agilent Part
Number
W8 W8 Cable, semi-rigid (with ferrites), A14 attenuator to A15
attenuator
E4440-20068
W80 W80 Cable, semi-rigid, Input Attenuator to Switch 1 (Option
123)
E4440-20090
W81 W81 Cable, semi-rigid (with ferrites), Switch 1 (bottom switch)
port 2 to RYTHM input (Option 123)
E4440-20091
W82 W82 Cable, semi-rigid, Switch 1 (bottom switch) port 1 to Mixer
input (Option 123)
E4440-20092
W83 W83 Cable, semi-rigid, Mixer LO IN to cable W88 from SLODA
LO Out (Option 123)
E4440-20093
W84 W84 Cable (1), coax, Dual Mixer Out to Switch 2 (top switch)
port 1 (Option 123)
E4440-60298
W86 W86 Cable (10), coax, 3rd Converter J1 to Switch 2 (top switch)
port C (Option 123)
E4440-60373
W87 W87 Cable (2), coax, RYTHM t o Switch 2 (top switch) port 2
(Option 123)
E4440-60373
W88 W88 Cable, semi-rigid, SLODA LO Out to cable W83 Mixer LO
In (Option 123)
E4440-20087
Dual Mixer A34 Dual Mixer (Option 123) 5086-7749
Top Switch SW2 RF Switch 2 Top Switch (Option 123) (must also order
shield, SW2. see Mechanical Parts table
33314-60013
Bottom
Switch
SW1 RF Switch 1 Bottom Switch (Option 123) 33314-60013
1 Bracket, Switch (Option 123) E4440-00020
Shield Shield, SW2 (Top Switch) (Option 123) E4440-00055
