Agilent Technologies E8257D PSG User Manual

22 Chapter 1
Signal Generator Overview
Rear Panel
Figure 1-5 Standard E8257D and E8663D Rear Panel
5. AUXILIARY I/O 19. AUXILIARY INTERFACE 26. SWEEP OUT
12. COH CARRIER (Serial Prefixes
>=US4646/MY4646)
20. 10 MHz IN 27. TRIGGER OUT
13. 1 GHz REF OUT (Serial Prefixes
>=US4646/MY4646)
21. LAN 28. TRIGGER IN
15. AC Power Receptacle 22. 10 MHz OUT 29. SOURCE SETTLED
16. GPIB 23. STOP SWEEP IN/OUT 30. SOURCE MODULE INTERFACE
17. 10 MHz EFC 25. Z–AXIS BLANK/MKRS
30
44
22
13
20
29
28
27 26 25 23 21 19
17
16 15
