Theory of Operation
Setting the 8-bit Configuration Switch
set of parameters is subsequently changed and power is reset. All other
previously stored configuration settings will still remain in the non-volatile
memory.
In this way you can store more than one set of parameters using the same
8-bit configuration switch twice, for example, for both GPIB and RS-232C.
GPIB Default Addresses
If you just want to change the GPIB address and need a detailed
procedure, refer to the Installing Your Agilent ChemStation System
handbook.
Default GPIB address is set to the following addresses:
where 0 means that the switch is down and 1 means that the switch is up.
Table 54 Default Addresses for Agilent Series 1100 Modules
0RGXOH $GGUHVV %LQDU\$GGUHVV
Pump 22 0 0 0 1 0 1 1 0
FLD 23 0 0 0 1 0 1 1 1
VWD 24 0 0 0 1 1 0 0 0
Agilent 8453A 25 0 0 0 1 1 1 0 1
DAD / MWD 26 0 0 0 1 1 0 1 0
Column
compartment
27 0 0 0 1 1 0 1 1
Autosampler 28 0 0 0 1 1 1 0 0
RID 29 0 0 0 1 1 1 0 1
