Agilent InfinityLab LC Series Multicolumn Thermostats User Manual 40
2 Site Requirements and Specifications
Valve Specifications
Table 11 G4234C (5067-4273), 6-Position/14-Port Valve 1300 bar
Type Specification
Maximum pressure 1300 bar
Typical application 6 column selection
Port size Accepts M4 male threaded fittings
Liquid contacts PEEK, Stainless steel
pH range
0 – 14
1
1
incompatible with some mineral acids. For more information see Solvent Information.
Table 12 G4234A (5067-4284), 6-Position/14-Port Valve 800 bar
Type Specification
Maximum pressure 800 bar
Typical application 6 column selection
Port size Accepts M4 male threaded fittings
Liquid contacts PEEK, Stainless steel
pH range
0 – 14
1
1
incompatible with some mineral acids. For more information see Solvent Information.
