Agilent InfinityLab LC Series Multicolumn Thermostats User Manual 67
3 Using the Module
Installing and Using Column ID Tags
1 Remove any tube guides and tube clip holders that may
already be installed on the sides of the MCT cover.
2 Unlock the left and right (G7116B only) side cover
inserts by pushing them to the rear and put them aside.
3 Identify the left and right (G7116B only) column ID mod-
ule. The ID sockets 1 to 4 are numbered from top to bot-
tom.
4 Take the end of the preinstalled flex-board connector
out of the holder.
1.
2.
