Agilent Technologies HS452 User Manual

Technical Information
Anti-Suckback Device
5
HS452, HS652 Rotary Vane Pumps User Manual / 87-900-978-01 (H) 57/102
Legend (cf. figure View of the Pump)
Tab. 2
N° Description HS452-652
1 Inverter motor assy SR03700703
2 Rubber foot
3 Screw
4 Screw
5 Screw
7 Spacer
8 Motor support
9 Handle
10 Screw
11 Right sideplate
12 Board
14 Screw
15 Support plate
16 Cylindrical pin (1) - (2)
17 Screw
18 Rubber crown (1) - (2)
19 Half-joint with fan
20 Half-joint (pump side)
21 Oil-seal ring (1) - (2)
22 Special screw
23 OR gasket (1) - (2)
24 Gas Ballast Valve knob
25 Half-plate
26 Inlet screen SR03700237
27 OR gasket (1) - (2)
28 Suction flange
29 Anti-suckback shutter (1) - (2)
30 Piston
