Technical Information
Accessories
5
HS452, HS652 Rotary Vane Pumps User Manual / 87-900-978-01 (H) 95/102
NOTE
You must exchange the 9 pin “D” mating connector shells with the IP44 version
even if you have no cable wired on the connector. In that case you have to use
the plastic cap as showed in the following figure.
Figure 14
Accessories
Tab. 12
PART NUMBER DESCRIPTION
949-9390 Rotary Vane Fluid DS19 Type 1 L. bottle
949-9395 Smart Pump Oil mist eliminator
949-9392 Smart Pump Exhaust filter
949-9376 Smart Pump Oil return kit
949-9382 Smart Pump major maintenance kit
949-9371 Smart Pump minor maintenance kit
949-9367 Smart Pump IP44 accessory kit
949-9396 Power cable EU
949-9397 Power cable US
949-9398 Power cable UK
949-9399 Power cable IEC320
