Anti-Suckback Device
5
HS452, HS652 Rotary Vane Pumps User Manual / 87-900-978-01 (H) 59/102
N° Description HS452-652
69A External oil pump gear SR03700281
69B Internal oil pump gear SR03700277
70 Oil pump cover
71 Screw
73 Plate
74 Filter
75 Casing
76 Exhaust flange
77 OR gasket (1) - (2)
78 Oil fill plug
79 Oil drain plug SR03700256
80 Oil drain plug gasket SR03700256
81 Left sideplate
83 Spring
84 Filter
86 Oil level indicator
99 Special screw
100 Piston
101 Arm
102 Spring (1)
103 OR gasket (1) - (2)
104 OR gasket (1) - (2)
105 Sleeve
106 Spring (1)
107 Ring (1) - (2)
108 Arm
109 Insert
110 Special washer
111 Screw
