Technical Information
RS 232/RS 485 Communication Description
5
HS452, HS652 Rotary Vane Pumps User Manual / 87-900-978-01 (H) 89/102
WIN TYPE DESCRIPTION
200 N BUS CURRENT [mA]
201 N 3PHASE VOLTAGE [Vrms]
202 N POWER [W]
203 N DRIVING FREQUENCY
[Hz]: (current driving frequency)
205 N STATUS
[0=stop ; 2=ramp ; 3=autotuning ; 5=normal ; 6=fail]
206 N ERROR CODE
Bit 7: motor block;
Bit 6: short circuit;
Bit 5: undervoltage;
Bit 4: motor over temperature;
Bit 3: power fail;
Bit 2: controller overt;
Bit 1: pump overt;
Bit 0: spare
211 N CONTROLLER TEMPERATURE [°C]
216 N ENVIROMENT TEMPERATURE [°C]
300 N CYCLE TIME [min]
301 N CYCLE NUMBER
302 N PUMP LIFE [h]
319 A CONTROLLER MODEL
323 A CONTROLLER SERIAL NUMBER
325 A ELECTRICAL MODIFICATION LEVEL
500 L Monitor Mode (write only)
503 N RS485 SERIAL ADDRESS SETTING
[0-31]
504 L SERIAL TYPE SELECT
(0=RS323; 1=RS485)
