Installing the GC 1
Agilent Intuvo 9000 GC Installation 19
If purchased, install the ALS tray support brackets.
If installing a 7693A ALS tray with this Intuvo 9000 GC, install
the pivot bracket, support bracket, and support truss now.
(Refer to the Intuvo 9000 7693A Tray Support Assembly,
accessory G7390A).
Intuvo 9000 7693A Tray Support Assembly kit contents
Install the pivot block and stop bracket
ALS support truss
Pivot block
Shoulder screw (0515-3005)
Tray bracket assembly
Stop bracket
Screws (0515-2113)
Screws for support truss (0515-6137)
Pivot block backers
To Next Page
