Agilent Technologies N6705

Agilent N6705 DC Power Analyzer
User’s Guide
 11
1
Quick Reference
The Agilent N6705 DC Power Analyzer – At a Glance ............................... 12
The Front Panel - At a Glance ......................................................................... 16
The Rear Panel – At a Glance ......................................................................... 17
Meter View ......................................................................................................... 18
Scope View ........................................................................................................ 19
Data Logger ........................................................................................................ 20
Arb Preview ........................................................................................................ 21
Front Panel Menu Reference .......................................................................... 22
This chapter concisely describes the operation of the Agilent N6705
DC Power Analyzer.
This chapter does not describe every operating feature in detail. It is
simply a quick reference guide to quickly become familiar with the
operating features of the Agilent N6705 DC Power Analyzer.
NOTE
Unless otherwise noted, the Agilent N6705 DC Power Analyzer will also be
referred to as “DC Power Analyzer” throughout this manual.
