Agilent Technologies N6705

Appendix B SCPI Commands
194 Model N6705 User’s Guide
Power-On Settings
These settings are set by the Reset (*RST) command
ARB:COUNt 1 ARB:FUNCtion:SHAPe NONE
ARB:CURRent|VOLTage:CDWell:DWELl 0.001 ARB:FUNCtion:TYPE VOLT
ARB:CURRent|VOLTage:CDWell:LEVel MIN ARB:SEQuence:COUNt 1
ARB:CURRent|VOLTage:EXPonential:END MIN ARB:SEQuence:STEP:COUNt 1
ARB:CURRent|VOLTage:EXPonential:STARt MIN ARB:SEQuence:STEP:FUNCtion:SHAPe PULS
ARB:CURRent|VOLTage:EXPonential:STARt:TIMe 0 ARB:SEQuence:STEP:PACing DWEL
ARB:CURRent|VOLTage:EXPonential:TCONstant
1
ARB:SEQuence:TERMinate:LAST
ON
ARB:CURRent|VOLTage:EXPonential:TIMe 1 ARB:TERMinate:LAST OFF
ARB:CURRent|VOLTage:PULSe:END 0 CALibrate:STATe OFF
ARB:CURRent|VOLTage:PULSe:STARt MIN CURRent 0.08 or MIN
ARB:CURRent|VOLTage:PULSe:STARt:TIMe 0 CURRent:LIMit MAX
ARB:CURRent|VOLTage:PULSe:TOP MIN CURRent:LIMit:COUPle ON
ARB:CURRent|VOLTage:PULSe:TOP:TIMe 1 CURRent:LIMit:NEGative MIN
ARB:CURRent|VOLTage:RAMP:END MIN CURRent:MODE FIX
ARB:CURRent|VOLTage:RAMP:END:TIMe 0 CURRent:PROTection:DELay 0.02
ARB:CURRent|VOLTage:RAMP:RTIMe 1 CURRent:PROTection:DELaySTARt SCH
ARB:CURRent|VOLTage:RAMP:STARt MIN CURRent:PROTection:STATe OFF
ARB:CURRent|VOLTage:RAMP:STARt:TIMe 0 CURRent:RANGe MAX
ARB:CURRent|VOLTage:SINusoid:AMPLitude MIN CURRent:TRIGger MIN
ARB:CURRent|VOLTage:SINusoid:FREQuency 1 CURRent:SLEW 9.9E+37
ARB:CURRent|VOLTage:SINusoid:OFFSet
0
CURRent:SLEW:MAX
ON
ARB:CURRent|VOLTage:STAircase:END 0 DIGital:OUTPut:DATA 0
ARB:CURRent|VOLTage:STAircase:END:TIMe MIN DISPlay:VIEW METER1
ARB:CURRent|VOLTage:STAircase:NSTeps 10 EMULation PS4Q (N6784A); PS2Q (N6781A, N6782A)
ARB:CURRent|VOLTage:STAircase:STARt
MIN
FUNCtion
VOLT
ARB:CURRent|VOLTage:STAircase:STAR:TIMe 0 FORMat:DATA ASCII
ARB:CURRent|VOLTage:STAircase:TIMe 1 FORMat:BORDer NORM
ARB:CURRent|VOLTage:STEP:END MIN INITiate:CONTinuous:TRANsient OFF
ARB:CURRent|VOLTage:STEP:STARt
MIN
LIST:COUNt
1
ARB:CURRent|VOLTage:STEP:STARt:TIMe 0 LIST:CURRent MIN
ARB:CURRent|VOLTage:TRAPezoid:END:TIMe 0 LIST:DWELl 0.001
ARB:CURRent|VOLTage:TRAPezoid:FTIMe 1 LIST:STEP AUTO
ARB:CURRent|VOLTage:TRAPezoid:RTIMe 1 LIST:TERMinate:LAST OFF
ARB:CURRent|VOLTage:TRAPezoid:STARt MIN LIST:TOUTput:BOST OFF
ARB:CURRent|VOLTage:TRAPezoid:STARt:TIMe 0 LIST:TOUTput:EOST OFF
ARB:CURRent|VOLTage:TRAPezoid:TOP MIN LIST:VOLTage MIN
ARB:CURRent|VOLTage:TRAPezoid:TOP:TIMe 1 OUTPut OFF
ARB:CURRent|VOLTage:UDEFined:BOSTep OFF OUTPut:COUPle OFF
ARB:CURRent|VOLTage:UDEFined:DWELl
0.001
OUTPut:DELay:FALL
0
ARB:CURRent|VOLTage:UDEFined:LEVel MIN OUTPut:DELay:RISE 0
