Agilent Technologies N6705

1 Quick Reference
14 Model N6705 User’s Guide
Power Module Features
Feature DC Power High-Performance Precision
(● = available) N673xB, N674xB, N677xA N675xA N676xA
50 W output rating N6731B – N6736B N6751A N6761A
100 W output rating N6741B – N6746B N6752A N6762A
300 W output rating N6773A – N6777A N6753A, N6754A N6763A, N6764A
500 W output rating N6755A, N6756A N6765A, N6766A
Output disconnect relays Option 761 Option 761 Option 761
Output disconnect/polarity reversal relays
NOTE 1
Option 760 Option 760 Option 760
Arbitrary waveform generation ● ● ●
Autoranging output capability ● ●
Voltage or current turn-on priority N6761A, N6762A
Precision voltage and current measurements ●
Low voltage and current output ranges N6761A, N6762A
Low voltage and current measurement ranges
●
200 microampere measurement range
NOTE 2
Option 2UA
Voltage or current scope traces
●
●
●
Simultaneous voltage and current scope traces ●
Simultaneous voltage and current data logging
NOTE 3
●
Interleaved voltage and current data logging
NOTE 3
● ●
Dynamic current correction ● N6751A, N6752A N6761A, N6762A
SCPI command list capability
NOTE 4
● ● ●
SCPI command array readback
NOTE 4
● ● ●
SCPI command programmable sample rate
NOTE 4
● ● ●
SCPI command external data logging
NOTE 4
● ● ●
Double-wide (occupies 2 channel locations) N6753A – N6756A N6763A – N6766A
Large gate array
NOTE 5
Option LGA
Notes:
1
Output current is limited to 10A max. on Models N6742B and N6773A with Option 760.
Option 760 is not available on Models N6741B, N6751A, N6752A, N6761A, and N6762A.
2
Option 2UA is only available on Models N6761A and N6762A. It includes Option 761.
3
Option 055 deletes the Data Logger function on Model N6705.
4
Only available when using the remote interfaces; not from the front panel.
5
Option LGA is required on Models N6751A and N6752A.
