Agilent Technologies N6705

Quick Reference 1
Model N6705 User’s Guide 15
Agilent N678xA Power Module Features
Feature Source/Measure Units (SMU) Application-Specific
(● = available) N6781A N6782A N6784A N6783A-BAT N6783A-MFG
Output rating 20 W 20 W 20 W 24 W 18 W
2-quadrant operation ● ● ● ●
4-quadrant operation ●
Auxiliary voltage measurement input ●
Output disconnect relays ● ● ● Option 761 Option 761
Arbitrary waveform generation
NOTE 1
●
●
●
●
●
Negative voltage protection ● ● ● ● ●
Voltage or current priority mode ● ● ●
CC load/CV load ● ● ●
Battery emulator/charger ● ● ●
Voltage/current measurement only ● ● ●
Programmable output resistance
●
600 mV output range ● ● ●
300 mA output range ● ●
100 mA, 10 mA output ranges ●
1 V, 100 mV measurement ranges ● ● ●
100 mA, 1 mA, 10 μA measurement ranges ● ● ●
150 mA measurement range ● ●
Voltage or current scope traces ● ● ● ● ●
Simultaneous voltage and current scope traces ● ● ●
Simultaneous voltage and current data logging
NOTE 2
● ● ●
Interleaved voltage and current data logging
NOTE 2
● ●
Seamless measurement autoranging ● ●
SCPI command list capability
NOTE 1, 3
● ● ● ● ●
SCPI command array readback
NOTE 3
● ● ● ● ●
SCPI command programmable sample rate
NOTE 3
● ● ● ● ●
SCPI command external data logging
NOTE 3
● ● ● ● ●
SCPI command histogram measurements
NOTE 3
● ●
Notes:
1
Arbitrary waveform generation and List capability are not available on the negative
current output on Model N6783A.
2
Option 055 deletes the Data Logger function on Model N6705.
3
Only available when using the remote interfaces; not the front panel.
