SH-110 Dry Scroll Vacuum Pump
D R A F T 4 / 1 7 / 1 2
Instructions for Use
General Information
This equipment is designed for use by professionals. The
user should read this instruction manual and any other
additional information supplied by Agilent before operat-
ing the equipment. Agilent will not be held responsible
for any events that occur due to non-compliance with
these instructions, improper use by untrained persons,
non-authorized interference with the equipment, or any
action contrary to that provided for by specific national
standards.
The SH-110 is a hermetic, dry scroll vacuum pump. This
pump is suitable for pumping air or inert gases. The pump
is not intended to pump corrosive, explosive, or particu-
late-forming gases.
The following paragraphs contain all the information nec-
essary to guarantee the safety of the operator when using
the equipment. Detailed information is supplied in
“Technical Information” on page 15.
This manual uses the following standard safety protocol:
Storage
When transporting and storing the pump, the following
environmental requirements should not be exceeded:
Preparation for Installation
The pump is supplied in a special protective packing. If
this shows signs of damage, which may have occurred
during transport, contact your local sales office.
Total weight of the packing, SH-110 pump included, is
approximately 20 kg (44 lbs).
WARNING The warning messages are for attracting
the attention of the operator to a partic-
ular procedure or practice which, if not
followed correctly, could lead to serious
injury.
CAUTION The caution messages are displayed
before procedures, which if not fol-
lowed, could cause damage to the
equipment.
NOTE The notes contain important informa-
tion taken from the text.
Temperature:
−
20 °C to +60 °C (
−
4 °F to 140 °F)
Relative humidity: 0 to 95% (non-condensing)
WARNING When unpacking the pump, be sure not
to drop it and avoid any kind of sudden
impact or shock vibration to it.
NOTE Normal exposure to the environment
cannot damage the pump. Neverthe-
less, it is advisable to keep the pump
inlet closed until the pump is installed
in the system.
