TriScroll 600 Series Vacuum Pump
DRAFT 6/13/11
Table 1 lists the available TS-600 pump models and
indicates the power cord to be used with each particular
pump.
Three phase pumps are shipped without a power cord.
A three phase power cable kit, Agilent part number
S4789001, is available. This kit does not include a plug.
Circuit Breakers
Table 2 lists the circuit breaker capacity required for pump
motors of various voltages, single and three-phase.
Table 1 Pump Models and Power Cords
Pump Model Motor Voltage Plug Type Fusing Conductor
Size
Cord Marking Cord
Length
PTS06001UNIV 100-115 VAC NEMA 5-15P - 14 Gage UL/CSA 2.5 m
PTS06001UNIVEU 200-230 VAC CEE 7/7 - 3x1.50 mm
2
<HAR> 2.5 m
PTS06001UNIVUK 200-230 VAC BS 1363 BS 1362
13 Amp
3x1.50 mm
2
<HAR> 2.5 m
PTS06003UNIV 200-230 VAC - - - - -
PTS06101UNIV 100-115 VAC NEMA 5-15P - 14 Gage UL/CSA 2.5m
PTS06001UVPI 100-115 VAC NEMA 5-15P - 14 Gage UL/CSA 2.5m
WARNING Protect against short circuits by
installing a circuit breaker of the
proper capacity.
Table 2 Circuit Breaker Requirements
Single Phase Motor 100-115 VAC
50/60 Hz
200-230 VAC
50/60 Hz
Breaker capacity 20 Amperes 10 Amperes
Three Phase Motor 200-230 VAC 380-415-460 VAC
Breaker capacity 10 Amperes 5 Amperes
