TriScroll 600 Series Vacuum Pump
DRA
FT 6/13/11
Technical Information
Table 17 Specifications
Model TriScroll™ 600 Series Dry Scroll Vacuum Pump
Interface dimensions See Figure 1
Peak pumping speed 50 Hz: 420 l/m, 25.2 m
3
/hr (14.8 cfm)
60 Hz: 500 l/m, 30 m
3
/hr (17.7 cfm)
Media Clean air. No toxic, corrosive, explosive or particulate forming gases
Ultimate pressure (Torr) 7.0 x 10
-3
Torr (9.3 x 10
-3
mbar)
Maximum inlet pressure 1.0 atmosphere (0 psig)
Maximum outlet pressure 1.1 atmosphere (1.5 psig)
Inlet connection NW40
Exhaust connection Female 3/8" National Pipe Thread (NW25 adapter provided)
Gas ballast Female 1/4" National Pipe Thread (40 Micron sintered filter provided)
Ambient operating temperature 5 °C to 40 °C (41 °F to 104 °F)
Storage temperature –20 °C to 60 °C (–4 °F to 140 °F)
Motor rating 1.0 HP (0.76 kW)
Operating voltages Single phase models:
❑ 50-60 Hz/100-115:200-230 VAC
Three phase models:
❑ 50 Hz/200-230:380-415 VAC
❑ 60 Hz/200-230:460 VAC
Motor full load currents See Table 18 on page 36
Motor thermal protection Type U automatic
Operating speed 60 Hz: 1725 RPM, 50 Hz: 1425 RPM
Cooling system Air-cooled
Weight Pump only: 32 kg (70 lbs)
Shipping weight: 40 kg (87 lbs)
Noise level (per ISO 11201) 68 dB(A)
Vibration level at inlet (per ISO 10816-1) 6.3 mm/sec
