TriScroll 600 Series Vacuum Pump
DRA
FT 6/13/11
Maintenance
General Information
Agilent TriScroll 600 series pumps are designed to provide years of trouble-free service if maintenance procedures and
intervals are observed. Bearing grease replenishment and tip seal replacement is recommended when pump base pressure
has risen to an unacceptably high level for your application. Bearings, rotary seals and o-rings should also be replaced if
the pump exhibits humming or grinding noises from the bearings. Main bearing life may be shortened if your application
requires the pumping of high quantities of water vapor. Use of the bearing purge kit (PTSPURGEKIT) mentioned earlier will
keep this water from impacting bearing life.
Maintenance should be performed in accordance with procedures, tooling and materials specified in the manuals listed
below.
Related TriScroll Manuals
Other manuals related to tip seal replacement, pump module replacement, and major maintenance of the TriScroll 600
series pumps are listed in Table 21.
Maintenance and Tooling Kits
Material and tooling required to perform maintenance on TriScroll pumps is provided in kit form. A description of each kit
and ordering information is provided in Table 22.
Table 21 Other Related Manuals
Title Applicable TriScroll Model Part Number
Tip Seal Replacement Manual All TriScroll 600 Series models 699904310
Pump Module Replacement Manual All TriScroll 600 Series models 699904305
Major Maintenance Manual All TriScroll 600 Series models 699904300
Table 22 Maintenance and Tooling Kits
Description Contents Applicable TriScroll Model Part Number
Major Maintenance Kit All bearings, bearing seals, bearing
lubricant, O-rings, and tip seals
required to rebuild TriScroll 600
series pumps.
All TriScroll 600 Series models PTSS0600MK
Maintenance Tool Kit All fixtures and tools required to
perform any maintenance on
TriScroll 600 Series pumps.
All TriScroll 600 Series models PTSS0600TK
Replacement Tip Seal Set Replacement tip seals and static
O-rings for TriScroll 600 Series
pumps.
All TriScroll 600 Series models PTSS0600TS
NOTE: The Maintenance Tool Kit is also required for tip seal replacement.
