DRAFT 6/13/11
TriScroll 600 Series Vacuum Pump
34
Figure 1 Interface Drawing with Dimensions
Figure 2 Pumping Speed Curves
355
(13.98)
13
(.50)
22
(.85)
Intake (NW40)
NW25 Exhaust extension
included but
not installed
Exhaust (
3
/8 NPT)
port swivels 360
ø300
(ø11.80)
472 (18.56) Three Phase
472 (18.57) Single Phase
184
(7.25)
38
(1.48)
105
(4.13)
82
(3.22)
145 (5.69)
102
(4.02)
176
(6.94)
4 x ø11(ø.43) Thru
