10 03-914852-00:4
7. Close the cover on the tower and power up the GC. The GC will
automatically sense the configuration of the switch and behave
accordingly.
`
Location of switch for configuration change on the
CP-8400/8410 Tower Sled Assembly
Note that sled has been
pushed down
compressing the foot and
guide rail in order to
reveal switch.
switch
