AGV COMPACT ST - Chin Air Vent Operation; Nose-guard Removal and Installation; Internal Padding Overview

18
3.2) Opening/closing the chin air vent
To open/close the chin air vent, operate the cursor as indi-
cated in the figure.
3.3) Nose-guard removal/installation
The nose guard can be removed, by gently extracting it
the special housings and check that it is properly secured.
4) INTERNAL PADDING
The crown pad, cheek pads and wind shield are removable and washable. To remove and install
padding, refer to the “Safety Warning” booklet.
Crown pad
Cheek pads with integrated neck roll
Wind shield
Closed
Open
Cursor
