Setting Up Your Aipas eBike Setting Up Your Aipas eBike
16 17
Install pedal
5
Installed on the other side
crank.
4
Looking for the "L" mark.
6
Rotate counterclockwise
to tighten.
2
Installed on the chainring
side crank.
1
Looking for the pedal with
the "R" mark.
3
Rotate clockwise to
tighten.
Adjust seat Position
Adjust Seat Post Height
Loosen the lamp. The open and closed positions of the clamp are shown below (open position
on left, closed position on right);
Raise or lower the seat post in the seat tube;
Check if the seat is straight and not tilted., and Re-tighten the seat post clamp to the recom-
mended torque. See Tightening Torque(p. 22).
Front and back adjustment: Loosen nuts on both sides of the seat. Make sure the clamp mecha-
nism is clamping on the straight part of the seat rails and is not touching the curved part of the
rails. Ensure that you are using the recommended torque on the clamping fastener(s). See Tight-
ening Torque (p. 22).
Seat angle adjustment: Most people prefer a horizontal seat, but you may prefer the seat nose
angled slightly up or down. Loosen the clamp bolt to allow any serrations on the clamp mecha-
nism to disengage before changing the seat angle, and to fully re-engage the serrations before
you tighten the clamp bolt to the recommended Tightening Torque (p. 22).
WARNING!
WARNING!
