Aiphone AC Series - Input Functions

11 | AC Series - Quick Start Guide
Input Functions
Disabled Will not react to any input status changes on the selected input.
REX (Request to Exit)
Allows the input to be used as a REX. Dry contact input can be
used to unlock the associated door via the input.
Door Contact
This input will track if the door is open or closed.
Note: If there is nothing connected to this contact and it is
enabled, the REX button will not work.
Door Opener to Exit
This input is generally used for handicapped operatiors for
activating automatic door openers. Automatic Opener must be
enabled in the Door Conguration Options.
Motion Sensor
This input function is used for external motion sensors. Unlock
By Motion must be selected in the Door Conguration Options.
AUX Input
This input function has the most congurable options, including
input actions such as pulsing outputs, overriding doors,
activating alarms.
Emergency Alarm
This input function is used to receive commands from
Emergency Alarm Systems. For example, this input can be
set to unlock the door and play a buzzer when a re alarm is
triggered.
External Alarm Status
This input function is used to monitor an alarm system status.
When the alarm is considered “Armed”, Readers will not accept
credentials unless the user associated with that credential has
the “Disengage Alarm” user privilege set to on.
Door Opener to Enter
This type of input is generally used for handicapped operators
for activating auto-door openers. Automatic opener must be
enabled in the door conguration options.
Door Unlocked or Open/Prevent Unlock
Used in mantrap congurations. When the door is open or
unlocked, this output will activate, is usually connected to an
input on another panel controlling access to the same area.
Connect to an input with the function “Door Prevent Unlock”.
